Fiber-to-the-Home Cable Production: How the Manufacturing Process Works
Quick fact: more than 70% of U.S. broadband rollouts now rely on fiber networks that require high-precision manufacturing to achieve required performance.
Shanghai Weiye OFC Equipment runs complete Fiber cable sheathing line manufacturing, from selecting brand fibers like Fujikura® or Corning® SMF-28e to final test reports that deliver 100% QA.
Our drop designs fit overhead, underground, and direct burial installation, with LSZH, PVC, and PE jacket options and core counts from 1 to 4 cores. We offer single-mode OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and logo printing.
Automated machines and high-precision equipment keep line speed steady and keep repeatability high. Typical lead times are 4–5 days for orders < 100 km and 7–10 days under 500 km, with an min. order of 1 km and warranty for free replacement on quality issues.
Continue to see how our materials, tests, and support help reduce lifecycle cost and align the product to your network needs.
- Shanghai Weiye OFC Equipment delivers full manufacturing with lab validation for U.S. deployments.
- Multiple jacket choices and optical grades cover varied installation environments.
- Automated production lines provide stable quality and stable optical performance.
- Fast lead times, low MOQ, and brand fiber options keep procurement predictable.
- Comprehensive test reports and after-sales warranty back product reliability and documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When schedules and performance count, Shanghai Weiye OFC Equipment delivers customized drop cables with full test documentation.
As a dedicated manufacturer, Shanghai Weiye OFC Equipment combines purpose-built equipment with stringent material control. We offer customized service and products for residential and MDU rollouts. Every order includes full QA coverage and full test reports.
Our lab runs high-temperature, salt-fog, and vibration testing to verify durability. Jacket options include LSZH, PVC, and PE. Designs include bow-type flat and self-supporting styles and use brand fibers such as Fujikura and Corning SMF-28e.
- Documented line control and production checks for auditable shipments.
- Engineering support for specification reviews, trials, and volume ramp.
- Modern fixtures and calibration minimize variation so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are aligned to network specifications, combining brand fiber choices with strict test routines.
Selecting Optical Fiber and Brands
We align fiber ribbon line to bend radius, attenuation, and deployment type. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning SMF-28e are available to meet procurement standards.
Strength member integration
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is ideal where non-conductive runs are required. Steel wire provides tensile strength for long-span aerial runs and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Closed-loop control of extruder temperature and capstan speed keeps line speed stable and critical dimensions.
| Member | Dielectric FRP | Steel wire |
|---|---|---|
| Use case | Non-conductive runs | High-tension aerial runs |
| Advantage | Lightweight, inert | High strength |
| Installer note | Simple terminations | Bonding/grounding required |
In-Process and Final Testing
Inline geometry/concentricity checks run during manufacturing. Final optical tests verify loss and return loss. Each order ships with a full test report and lab results from high heat, salt-spray, and vibration trials to confirm handling for drop terminations and field use.
Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Lot records and FAI approvals support traceability and compliance for U.S. programs.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment offers a compact portfolio of drop designs that suit both tight indoor routes and exposed aerial spans. Each option combines tested materials with field-termination geometry and stable optical performance.
The flat bow-type drop minimizes footprint for risers and conduit. It reduces bend loss for simple routing in hallways and MDUs.
Self-supporting designs for aerial spans
Self-supporting FTTH drop designs include a messenger element to carry tensile loads. Choose FRP (dielectric) for non-conductive runs or steel messenger when bonding/grounding and higher tensile strength are required.
Layouts & Strength Members
We offer both dielectric and metallic strength member configurations to meet safety/EMI requirements. Central loose-tube and unitube flat types balance crush resistance and compact fiber unit for quick termination.
Jackets for Indoor/Outdoor
Jacket choices include LSZH for indoor flame/smoke compliance and PE for outdoor UV and moisture resilience. Each series is validated for mechanical/optical performance before shipment.
| Design | Best use | Strength member | Jacket |
|---|---|---|---|
| Flat bow-type | Indoor risers and MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Aerial spans | Steel wire or FRP | PE |
| Center loose tube | Higher fiber counts | FRP | LSZH/PE |
| Flat unitube | Low count, quick strip | FRP/Steel | LSZH/PE |
Production Assets for Speed and Quality
Automation with sensor feedback at Shanghai Weiye OFC Equipment cut manual handling and boost throughput for patch cord prep.
Our production line uses automated machines that cut and strip drop patch cords to increase output and reduce operator variability.
The CLX-BPO2 automated stripper runs under PLC and photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise stub lengths. Pneumatic cylinder actuators deliver fast, repeatable motion and low downtime.
PLC & Photoelectric for Precision
PLC logic and photoelectric sensors deliver precise positioning and closed-loop control. Inline checks feed control charts so operators can adjust drifts before defects grow.
| Item | Capability | Result |
|---|---|---|
| Machine | Auto-strip, ~1.5 s cycle | High throughput |
| Drive | Pneumatic cylinders | Fast/reliable motion |
| Material handling | LSZH/PVC; FRP/steel | Accurate stubs, clean terminations |
| Control | PLC/photoelectric with in-line SPC | Consistent quality, lower rework |
- Automated waste ejection and ergonomic feeders maintain clean workcells.
- PCPs document calibration and key parameters.
- Combined machines, fixtures, and trained staff support FTTH volume targets without sacrificing accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, reducing cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC/photoelectric control enable precise detection and repeatable actuation. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is 1.5s per cycle. This translates to steady throughput under continuous line conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable strip length from 17.5 to 35.0 mm. Reserved stubs are set between 7.0 and 11.0 mm to fit common termination hardware.
FRP & Steel Member Handling
The machine cleanly cuts FRP and steel wire strength elements while protecting adjacent fibers. Customized cutters are offered for non-standard cross-sections to maintain precision.
- Automatic waste ejection and sensor-triggered start cut idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass simplify cell integration.
- Cylinder-driven motion and closed-loop control boost reliability and lower maintenance interruptions.
| Specification | Value | Why it matters |
|---|---|---|
| Cycle time | ~1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Compatible with common connectors |
| Stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power & size | 50W @ 110–220V; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 helps our production lines meet volume goals without compromising quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures every order to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1 to 4 cores with single-mode or multimode fiber. Options include OS1/OS2 plus OM2–OM4 plus G.652D/G.657 variants to align with optics and connector plans.
We match sheath colors to Pantone codes for fast field ID and consistent asset tags.
Branding and Print Options
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom legends/logos aid inventory/warranty tracking.
Lengths, Packaging & Special Builds
Standard reel lengths are 1 km, 2 km, and 4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.
| Choice | Typical | Benefit |
|---|---|---|
| Length | 1 / 2 / 4 km | Less staging, easier reels |
| Sheath | LSZH, PE, PVC | Indoor/Outdoor fit |
| Structure | Flat bow / Self-supporting | Routing and span flexibility |
As a supplier, Shanghai Weiye schedules runs to your plan and delivers documentation that lists final specifications for easy on-site QA.
Quality assurance, testing, and documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item ships with recorded acceptance data.
Environmental and Mechanical Tests
Our lab conducts elevated-temperature exposure, salt fog corrosion, and mechanical vibration to qualify materials and assemblies. These tests recreate field stresses for indoor/outdoor applications.
Per-Reel 100% Reports
Every fiber optic cable ships with a 100% test report that logs attenuation, return loss, and geometry where applicable. Final QC gates prevent nonconforming shipments before they leave the factory.
Traceability and compliance
Batch records link tests to reels/serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- Line checks and final inspection prevent field failures and lower warranty events.
- QA packages include specifications confirmation and formatted data for quick review.
- Continuous test trends drive preventive maintenance and improve long-term reliability.
| Trial | Why | Result |
|---|---|---|
| High-temperature | Thermal stability | Validated heat endurance |
| Salt spray | Corrosion resistance | Outdoor suitability |
| Vibration | Mechanical robustness | Improved field reliability |
Cost Drivers and Pricing
Budget planning for a drop begins with fiber/jacket selection and is shaped by volume and customization.
Typical prices range broadly—from about $30 to $1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket chemistry (LSZH, PVC, PE), length, and structural design.
Materials, Grade, Jacket & Structure
The primary cost drivers are fiber grade, jacket material, and the chosen structure for deployment.
Self-supporting structures and steel strength elements raise material and labor input. Custom colors, logos, and print legends add setup time and impact pricing on small runs.
How Volume & Options Affect Cost
Longer put-ups and larger volumes lower unit cost. Short runs often carry setup fees and higher unit prices.
- Changeovers and special cutters extend lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Factor | Price impact | Recommendation |
|---|---|---|
| Fiber grade | High impact | Right-size spec to budget |
| Jacket type | Medium impact | Compare LSZH vs. PE for total cost |
| Length/Volume | High impact | Consolidate runs to cut unit cost |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable schedules cut downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We schedule line capacity to match your rollout milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For compressed schedules, we reserve contingency capacity to pull in critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects line setup such as wire/die adjustments that consume start-up material and scrap.
We review your put-ups and staging to select reels to reduce waste/handling. Batch releases can balance inventory holding with more frequent small-site deliveries.
Installation readiness and application scenarios
On-site conditions determine whether a self-supporting aerial, ducted pull, or direct-buried run is the right choice for a project.
Aerial, duct, and direct-buried deployment considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to manage sag/tension for long-term stability.
Duct installations perform best with low-friction sheaths and crush-resistant builds so pulling does not damage fibers. PE jackets are typical for underground and buried paths where moisture resistance is needed.
Direct-buried designs need correct burial depth per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor Distribution and ONT
Indoor riser and plenum routes prefer LSZH to meet flame and smoke rules. Flat drop profiles strip cleanly and present controlled strength stubs for quick ONT termination.
We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning exposure, and hardware compatibility. Standardized prep from the production line shortens install time and minimizes scrap.
| Deployment | Key design | Field note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Duct | Low-friction jacket, crush resistance | Use pull tape and proper lubricant |
| Direct burial | PE jacket, moisture barrier | Follow depth/warning tape codes |
| Interior | LSZH with tight-bend support | Maintain bend radius at penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
Comprehensive Support & After-Sales
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements capture through approved drawings and pre-production builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full test reports and traceability to help QA acceptance.
- Round-the-clock availability for status updates and technical guidance.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for expedites and urgent changes.
- Configuration control so shipped items match agreed specs consistently.
| Area | Scope | Outcome |
|---|---|---|
| Tech/Eng | Specs + pilots | Fewer field issues |
| Testing | Lab + 100% reports | Full traceability |
| After-sales | Fast replace + RCA | Lower downtime |
Final Thoughts
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel includes a 100% test report and documented lab trials to support field acceptance in the United States.
A robust production line, including CLX-BPO2-enabled prep machines, reduces variability and shortens turnaround. Our equipment set standardize strip/stub lengths so installers get consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated customer support covers scheduling/logistics/after-sales so your deployment remains on plan.
Contact Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive support.
